Current Carrying Capacity: 250 A
Breaking Capacity: 150 V / 2.3 kA / 7 μH
Resistance (Ambient): Before Breaking ≤ 0.2 mΩ, After Breaking ≥ 100 MΩ / 1150 V
Flip-flop Resistance: 2.0±0.3 Ω
Flip-flop Trigger Current: 1.75 A / 0.5 ms or 1.20 A / 2.0 ms
Flip-flop Safety Current: ≤ 0.4 A
Flip-flop Insulation Resistance: 1 MΩ (500 VDC / 2 s)
